Essentials
Product Collection - 13th Generation Intel® Core™ i7 Processors
Code Name - Products formerly Raptor Lake
Vertical Segment - Desktop
Processor Number - i7-13700
Lithography - Intel 7
Recommended Customer Price - $384.00 - $394.00
Use Conditions - PC/Client/Tablet | Workstation

CPU Specifications
Total Cores - 16
# of Performance-cores - 8
# of Efficient-cores - 8
Total Threads - 24
Max Turbo Frequency - 5.20 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡ - 5.20 GHz
Performance-core Max Turbo Frequency - 5.10 GHz
Efficient-core Max Turbo Frequency - 4.10 GHz
Performance-core Base Frequency - 2.10 GHz
Efficient-core Base Frequency - 1.50 GHz
Cache - 30 MB Intel® Smart Cache
Total L2 Cache - 24 MB
Processor Base Power - 65 W
Maximum Turbo Power - 219 W

Supplemental Information
Marketing Status - Launched
Launch Date - Q1'23
Embedded Options Available - Yes

Memory Specifications
Max Memory Size (dependent on memory type) - 128 GB
Memory Types - Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels - 2
Max Memory Bandwidth - 89.6 GB/s
ECC Memory Supported ‡ - Yes

Processor Graphics
Processor Graphics ‡ - Intel® UHD Graphics 770
Graphics Base Frequency - 300 MHz
Graphics Max Dynamic Frequency - 1.60 GHz
Graphics Output - eDP 1.4b | DP 1.4a | HDMI 2.1
Execution Units - 32
Max Resolution (HDMI)‡ - 4096 x 2160 @ 60Hz
Max Resolution (DP)‡ - 7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡ - 5120 x 3200 @ 120Hz
DirectX* Support - 12
OpenGL* Support - 4.5
OpenCL* Support - 3
Multi-Format Codec Engines - 2
Intel® Quick Sync Video - Yes
Intel® Clear Video HD Technology - Yes
# of Displays Supported ‡ - 4
Device ID - 0xA780

Expansion Options
Direct Media Interface (DMI) Revision - 4
Max # of DMI Lanes - 8
Scalability - 1S Only
PCI Express Revision - 5.0 and 4.0
PCI Express Configurations ‡ - Up to 1x16+4 | 2x8+4
Max # of PCI Express Lanes - 20

Package Specifications
Sockets Supported - FCLGA1700
Max CPU Configuration - 1
Thermal Solution Specification - PCG 2020C
TJUNCTION - 100°C
Package Size - 45.0 mm x 37.5 mm

Advanced Technologies
Intel® Gaussian & Neural Accelerator - 3
Intel® Thread Director - Yes
Intel® Deep Learning Boost (Intel® DL Boost) - Yes
Intel® Speed Shift Technology - Yes
Intel® Turbo Boost Max Technology 3.0 ‡ - Yes
Intel® Turbo Boost Technology ‡ - 2
Intel® Hyper-Threading Technology ‡ - Yes
Intel® 64 ‡ - Yes
Instruction Set - 64-bit
Instruction Set Extensions - Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle States - Yes
Enhanced Intel SpeedStep® Technology - Yes
Thermal Monitoring Technologies - Yes
Intel® Volume Management Device (VMD) - Yes

Warranty:
Product is thoroughly tested and completely functional without any issues. We also provide a one month warranty from our end.
